SDI Video Inputs

1 x SD, HD or 6G-SDI. 1x ALT SDI Input for automatic
switch over if main input fails

SDI Video Output

1 x Embedded SDI Output.

Analog Audio Outputs

4 channels of balanced analog audio.

Digital Audio Outputs

8 channels of balanced digital audio.

SDI Redundant Inputs

Automatically switches over if main input fails

Multi Rate Support

Auto detection of SD, HD or 3G-SDI.

Updates and Configurations

Via USB 2.0 high speed (480 Mb/s)

Reclocking

Yes

SD Video Standards

525i59.94 NTSC, 625i50 PAL

HD Video Standards

720p50, 720p59.94, 720p60, 1080p23.98,
1080p24, 1080p25, 1080p29.97, 1080p30,
1080p47.95, 1080p48, 1080p50, 1080p59.94,
1080p60, 1080PsF23.98, 1080PsF24, 1080PsF25
1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94,
1080i60

2K Video Standards

2Kp23.98 DCI, 2Kp24 DCI, 2Kp25 DCI,
2Kp29.97 DCI, 2Kp30 DCI, 2Kp47.95 DCI,
2Kp48 DCI, 2Kp50 DCI, 2Kp59.94 DCI, 2Kp60 DCI,
2KPsF23.98 DCI, 2KPsF24 DCI, 2KPsF25 DCI,
2KPsF29.97 DCI, 2KPsF30 DCI

SDI Compliance

SMPTE 259M, SMPTE 292M, SMPTE 296M,
SMPTE 372M, SMPTE 424M level B, SMPTE 425M
ITU-R BT.656 and ITU-R BT.601

SDI Video Rates

SDI video inputs are automatically detected between
standard definition, high definition and level B 3G-SDI.

SDI Video Sampling

4:2:2, 4:4:4

SDI Audio Sampling

Television standard sample rate of 48 kHz and 24 bit.

SDI Color Precision

4:2:2, 4:4:4

SDI Color Space

YUV, RGB

SDI Auto Switching

Automatically detects SD, HD, 3G-SDI

Software Control

Mac OS and Windows software upgrade via USB.

Internal Software Upgrade

Via included updater application.

Mac 10.15 Catalina,
Mac 11.1 Big Sur or later
Windows 10, 64-bit.

Mini Switches or USB Software.

Power Supply

+12V universal power supply included with
international socket adapters for all countries.
Cable tie point

Power Consumption

8.40W

Operational Voltage Range

12-31V DC

Operating Temperature

0° to 40° C (32° to 104° F)

Storage Temperature

-20° to 45° C (-4° to 113° F)

Relative Humidity

0% to 90% non-condensing
