Input & Loop-through Interface

One SD/HD/3G/2K/6G SDI input + embedded audio
One SDI loop-through
Support input & loop-through resolution up to 4096×2160 pixels

Audio Input/Output Interface

3.5mm audio Line In/Line Out for microphone/ headphones

Host Interface

USB 3.0, compatible with USB 2.0

Windows, Linux, Mac, Chrome OS

Support capture resolutions up to 3840x2160p 30fps or 1920x1080p90
Capture 2-channel embedded audio or analog audio via 3.5mm unbalanced Line In interface
Capture SDI signals transmitted a long distance away: up to 150m for 3G-SDI signals, 75m for 6G-SDI signals
CActual frame rate can be limited by the host and resolution

OS

USB Capture Utility, Capture Express, etc.

Compatible Software

Zoom Rooms, Microsoft Teams Rooms, Skype for Business, Google Hangouts, GoToMeeting, VLC, OBS Studio, XSplit, etc.

Auto detection of input signal format
Windows, Linux and Mac SDK
Continously Work for 24hx7
LED Status Indicator
3-year Warranty
